This Cisco CWDM-SFP25G-1270-10 Compatible SFP28 transceiver provides 25GBase-CWDM throughput up to 10km over single mode fiber (SMF) using a wavelength of 1270nm via an LC duplex connector. It provides 25GBASE Ethernet connectivity option for 25G Ethernet, telecom and data center. It is fully compliant with the SFP28 MSA, CPRI and eCPRI standard.
Product Specification:
Cisco Compatible | CWDM-SFP25G | Vendor Name | SURPATEK |
Form Factor | SFP28 | Max Data Rate | 25.8Gbps |
Wavelength | 1270nm – 1570nm | Max Cable Distance | 40km |
Connector | LC duplex | Media | SMF |
Transmitter Type | DFB CWDM | Receiver Type | PIN |
DDM/DOM | Supported | Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
TX Power | 0~6dBm | Receiver Sensitivity | <-14dBm |
Power Consumption | 1.3W | Extinction Ratio | 3.5dB |
Modulation Format | NRZ | CDR | TX and RX |
Transmit and Dispersion Penalty | 1dB | Powerbudget | 14dB |
Packaging Technology | TO-CAN Packaging | FEC Function | Not Supported |
Protocols | MSA Compliant, CPRI, eCPRI | Application | 25GBASE Ethernet, Data Center, Telecom |
