ONU XPON 1G1FE+WIFI

ONU XPON 1G1FE+WIFI

Accept OEM & ODM customization
Support EPON/GPON mode and switch mode automatically
Support Route mode for PPPoE/DHCP/Static IP and Bridge mode
Support IPv4 and IPv6 dual mode
Support 2.4G WIFI and Multiple SSID
Support LAN IP and DHCP Server configuration
Support Port Mapping and Loop-Detect
Support Firewall function and ACL function
Support IGMP Snooping/Proxy multicast feature
Support TR069 remote configuration and maintenance
Specialized design for system breakdown prevention to maintain stable system
Compatible with HUAWEI,ZTE,Fiberhome,V-Sol,HSQ ,etc over 95% brands of OLTs on the market
Technical support services by team of engineers.

HUR3108XR is designed as HGU (Home Gateway Unit) in different FTTH solutions. The carrier-class FTTH application provides different services.
HUR3108XR is based on mature and stable, cost-effective XPON technology.
HUR3108XR adopts high reliability, easy management, configuration flexibility and good quality of service guarantees to meet the technical performance of EPON Standard of China Telecom CTC3.0 and GPON Standard of ITU-TG.984.X

Technical item	Details
PON Interface	1 GPON BOB （Bosa on Board）
	Receiving sensitivity: ≤-28dBm
	Transmitting optical power: +1~+4dBm
	Transmission distance: 20KM
Wavelength	TX: 1310nm, RX: 1490nm
Optical Interface	SC/UPC Connector
Design Scheme	RTL9603C+RTL8192FR BOB(RTL8290B)
Chip Spec	CPU 950MHz,DDR2 128MB
Flash	SPI Nor Flash 16MB
LAN Interface	1 x 10/100/1000Mbps(GE) and 1 x 10/100Mbps(FE) auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
Wireless	Compliant with IEEE802.11b/g/n,
	Operating frequency: 2.400-2.4835GHz
	support MIMO, rate up to 300Mbps,
	2T2R,2 external antenna 5dBi,
	Support: Multiple SSID
	Channel: Auto
	Modulation type: DSSS, CCK and OFDM
	Encoding scheme: BPSK, QPSK, 16QAM and 64QAM
LED	7 LED, For Status of WIFI、WPS、PWR、LOS、PON、LAN1~LAN2
Push-Button	3,For Function of Reset, WLAN, WPS
Operating Condition	Temperature: 0℃~+50℃
Operating Condition	Humidity: 10%～90%（non-condensing）
Storing Condition	Temperature: -30℃~+60℃
Storing Condition	Humidity: 10%~90%（non-condensing）
Power Supply	DC 12V/1A
Power Consumption	≤6W
Dimension	155mm×92mm×34mm（L×W×H）
Net Weight	0.24Kg

What is your company product?

Our main product ranges Fusion Splicer,SFP+ Modules,GEPON OLT, GEPON XPON ONU, and fiber optic accessories,like fast connectors,adapters,splitters,drop cable,patch cord...with good quality and factory direct price.

What is your payment terms?

T/T 30% as deposit, and 70% before delivery. We'll show you the prepared photos of the products and packages before you pay the balance.

Can we get free samples?

Of course, please find our sales manager to get your free sample.

Can I customized the products?

Some products are customized, any specification will be accepted. Please kindly tell our your request.

What is your terms of trade?

We offer EXW,FOB,CIF,CNF and DDP or as your request.

How long is the warranty?

We provide customers with 2 year warranty service, and our business with us for more than 1 year will provide 3 years warranty service.

Can I get a sample first?

Of course, you can get a sample to test first, I make sure you will reorder and be happy with our high quality goods.

What is your delivery time about the production?

Generally, it will take 3 to 5 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.Large quantity will delivery faster.

What is your shipment items?

We can ship the items by DHL, FedEx, TNT, UPS, EMS, Aramex and China Mail Post.
Of course, we can also use cheaper shipping methods, such as by sea.It can reduce your costs even more and help you build a more advantageous business.If you are importing from another country for the first time and have no previous import experience, we also have DDP (DDP means you don't need to pay any tax) option available, please contact our sales consultant.

How can I contact you?

Send your Inquiry Details in the Below, Click "Send" Now........don't hesitate.
