FBT Splitter 1*32 FC-APC Fiber Optic Box splitter 1 in 32
The FBT Splitters is branching devices that is used to distribute optical signals to multiple locations for processing. In optical networks, it is often necessary to split an optical signal into many identical signals, or to combine many signals into a single signal.
FBT Splitter is a type of optical power management device that is fabricated using silica optical wave guide technology. They are designed for FTTx Passive Optical Networks, CWDM, DWDM and optical cable TV System.FBT Splitter is responsible to distribute optical signals from Central Office (CO) to multiple premise locations.
Application:
1. FTTX networks
2. PON networks
3. CATV links
4. Data Communication
Feature:
1. Low Insertion Loss
2. Low Polarization Dependent Loss
3. Wide Operation Wavelength
4. Wide Operation Temperature
5. High Stability and Reliability
| Operating Wavelength | 1260nm-1650nm | |||||
| Test Wavelength | 1310nm,1550nm | |||||
| Parameters | 1×2 | 1×4 | 1×8 | 1×16 | 1×32 | 1×64 |
| Insert loss (dB) | ≤4.1 | ≤7.4 | ≤10.5 | ≤13.8 | 17.1 | 20.4 |
| Uniformity | ≤0.8 | ≤0.8 | ≤0.8 | ≤1.0 | ≤1.5 | ≤2.0 |
| PDL (dB) | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 |
| WDL (dB) | ≤0.8 | ≤0.8 | ≤0.8 | ≤1.0 | ≤1.0 | ≤1.0 |
| Return loss | UPC ≥ 50dB, APC ≥ 50dB | |||||
| Directivity | ≥ 55dB | |||||
| Standard Input Fiber | Φ0.9/2.0/3.0mm | |||||
| Standard Output fiber | Φ0.9/2.0/3.0mm | |||||
| Fiber Type | G657A1 or Customized | |||||
| Working temperature | -40~85°C | |||||
| Storage temperature | -40~85°C | |||||
| Connector Options | SC/LC/FC/ST | |||||
| Type Options | Bare Device /Mini Tube / ABS Module | |||||
